Manufacturing Lab

Sherline 4400 Series 3.5" x 17" Lathe

Sherline

A high-torque 90VDC motor with variable speed control which is internally equipped with a converter that automatically adjusts to incoming AC current from 100 to 240 volts, 50 or 60 cycles/sec without loss of torque; 24" (610 mm) bed that has 17" (431 mm) between centers; 2.5" (63 mm) resettable "zero" handwheel on the leadscrew, plus two deluxe 2" (51 mm) resettable "zero" handwheels on the feed screw and crosslide; 2.75" (70 mm) x 6.0" (152 mm) crosslide with two T-slots; rocker tool post in place of standard type; two position pulleys; Kevlar reinforced drive belt and adjustable anti-backlash.

Manufacturing Lab

Buehler IsoMet Low Speed Saw

Buehler IsoMet

The Buehler IsoMet Low Speed cutting machine is a precision sectioning saw that is designed for cutting various types of materials with minimal deformation. This low speed precision cutter is targeted for delicate parts by only using gravity fed force. Low speed sectioning tool capable of cutting virtually any material including brittle or ductile metals, composites, cements, laminates, plastics, electronic devices and biomaterials.

Manufacturing LAB

Wire Saw – MODEL 850 – Abrasive Slurry Saw

The Wire Saw offers the most gentle mechanical method for cutting virtually any material using either a diamond impregnated wire blade or a plain wire blade with an abrasive slurry. In addition to traditional mechanical cutting, the saw can also be used as a string saw to cut water soluble crystals. It is most useful for cutting fragile crystals, substrates with delicate layers or any material that would be damaged when using a diamond wheel saw. Very brittle materials will cut the fastest, but even soft materials can be cut since there is not the problem of loading the blade that is inherent with diamond or abrasive wheels. The Wire Saw has sample holders available to hold virtually any shape sample including a goniometer to simplify the cutting of oriented crystals.

Manufacturing LAB

IsoMet 1000 Precision Saw

Buhler

The IsoMet 1000 is a precision sectioning saw is designed for cutting various types of materials with minimal deformation. This precision cutting machine is ideal for delicate parts by only using gravity fed force. Its great versatility in chucking allows for holding all types of sample shapes and configurations giving today’s laboratory a precision cutting machine capable of sectioning virtually any material including brittle or ductile metals, composites, cements, laminates, plastics, electronic devices, and biomaterials.

Manufacturing LAB

OM100 Universal Testing machine

Microtensile

A versatile, precise, easy to use and program machine. Used for mechanical testing of medical and dental materials within the technical standards. It has a wide range of accessories and devices that make it an excellent tool to equip your laboratory. Designed for the dental area, it has security systems against overloads that prevent damage to the load cell, serial connection to a computer and test monitoring software with the generation of graphs, calculations and results.

Manufacturing LAb

Speed Drill Press

General International’s 10 inch 5 Speed Drill Press delivers the power you need for your garage or work shop. Loaded with features you would expect in an industrial type drill presses. Choose from 5 speeds to perfectly match the ideal cutting conditions you need for your material. Featuring our patented cross-pattern precision laser guide system, this drill press is perfect for home or worksite.

Manufacturing LAb

Red-Wing lathe 26A

Red-Wing

Standard bench polishing and grinding lathe ideal for the office or lab. A maintenance free 1⁄4 HP motor powers the 1725/3450 rpm lathe. Provided with standard dental, tapered shafts. Includes left-chuck and right-chuck remover for easy removal of standard dental chucks. The 4½" shaft height and standard tapered shafts will accommodate almost all dental lathe accessories.

Manufacturing LAb

Handpiece Motor Forza L50K

Brasseler USA

The Forza L50K Lab system with brushless micromotor offers powerful torque for more demanding laboratory procedures. The handpiece shape has been designed for ergonomy and functionality. The result is a handpiece which considerably reduces hand fatigue and makes it easier to work on even the most delicate pieces of work for extended periods of time. The unique dust-proof mechanism prevents contamination therefore achieving higher durability. The easy-to-operate control unit features a digital speed display, an auto-cruse mode and forward/reverse modes. The Forza L50K lab system operates at a speed range of 1,000-50,000 rpm, a maximum torque of 8.7 Ncm and the handpiece weight is only 219 grams.

Manufacturing LAb

Gypsum Model Trimmer

Ray Foster

Ray Foster Model Trimmers are constructed from heavy gauge cast aluminum with stainless steel and solid brass fittings. The machines are finished, inside and out, with a high gloss white epoxy coating that offers durability, corrosion resistance, and a very attractive finish. Resiliently mounted and precision balanced for smooth, quiet operation, they are designed to assure years of service free performance under the most demanding laboratory use. The Ray Foster Model Trimmers are the original "swinging door" trimmer and is the benchmark by which other model trimmers are measured.

Manufacturing LAb

Ecomet 250 Grinder Polisher

Buehler

The EcoMet line of grinder and polisher machines are built for demanding production lab environments. The Ecomet250 is designed for manual or automated sample preparation. Simplicity is balanced with versatility to accommodate many applications. The Ecomet 250 is built with durable construction for reliability in high use environments, unique quick cleaning features, and plenty of enhancements for user friendly operation.

Manufacturing LAb

Whip Mix Vaccum Mixer

Whip Mix Corporation

The Vacuum Power Mixer Plus provides a single drive speed of 425 RPM. This slow speed is ideal for mixing quantities from 5 gram to 1,000 gram of plaster, stone, die material, investment and alginate.
